Festo
172953
On/off valve HEE-1-D-MAXI-24
The Festo 172953 is an electrically actuated piston gate valve featuring a 3/2-way, closed, monostable valve function with piloted control and a soft sealing principle. This component delivers a normal nominal flow rate of 6500 l/min at an operating pressure range of 0.25 MPa to 1.6 MPa, utilizing a mechanical spring reset and detenting manual override. Designed with a 100% duty cycle and 24 V DC, 2.5 W coil characteristics, it operates on compressed air meeting ISO 8573-1:2010 [7:4:4] or inert gases with possible oil lubrication. Please submit the exact part number, quantity, and application requirements to request a quote.
View product details →
Festo
170866
Guided drive DFM-40-80-P-A-GF
The Festo 170866 is a double-acting industrial drive unit featuring a 40 mm piston diameter, an 80 mm stroke, and a yoke operating mode with a plain-bearing guide. It operates within a pressure range of 0.15 MPa to 1 MPa (1.5 bar to 10 bar), accommodating compressed air as per ISO 8573-1:2010 [7:4:4] with a max speed of 0.8 m/s and elastic cushioning rings or pads at both ends. Constructed with a center of gravity distance of 50 mm from the payload to the yoke plate, it achieves a maximum force Fy of 1227 N and an impact energy of 0.7 Nm in the end positions across an ambient temperature range of -20 °C to 80 °C. Submit the exact part number, quantity, and application requirements for a quote.
View product details →
Festo
172952
On/off valve HEE-3/4-D-MAXI-230
The Festo 172952 is an electrically actuated piston gate valve featuring a soft sealing principle, positive overlap lap, and a 3/2-way, closed, monostable valve function with piloted control. Engineered for compressed air per ISO 8573-1:2010 [7:4:4] or inert gases within an operating pressure range of 0.25 MPa to 1.6 MPa, this component delivers a normal nominal flow rate of 6000 l/min with a 100% duty cycle. It operates on 230 V AC at 50/60 Hz with permissible voltage fluctuations of -14% / +10%, includes a detenting manual override, mechanical spring reset, and features a moderate corrosion resistance class (CRC 2) along with RoHS-compliant materials. Submit the exact part number, quantity, and application requirements to receive a formal quote.
View product details →
Festo
170865
Guided drive DFM-40-50-P-A-GF
The Festo 170865 is a double-acting industrial guide drive unit featuring a 40 mm piston diameter and a 50 mm stroke, operating via a yoke drive mode with elastic cushioning rings or pads at both ends. Designed with a plain-bearing guide, it supports a maximum speed of 0.8 m/s, an operating pressure range of 1.5 bar to 10 bar, and a maximum force Fy of 1227 N with the center of gravity of the payload to yoke plate xs at 50 mm. Position sensing is accomplished via proximity switch, and the unit operates using compressed air as per ISO 8573-1:2010 [7:4:4] within an ambient temperature range of -20 °C to 80 °C. Submit the exact part number, quantity, and application requirements for an official quote.
View product details →
Festo
172950
On/off valve HEE-3/4-D-MAXI-24
The Festo 172950 is an electrical piston gate valve featuring a 3/2-way, closed, monostable valve function with a soft sealing principle and positive overlap. Engineered for a normal nominal flow rate of 6000 l/min and an operating pressure range of 0.25 MPa to 1.6 MPa, this piloted component operates on compressed air to ISO 8573-1:2010 [7:4:4] or inert gases with a 100% duty cycle at 24 V DC and 2.5 W. It incorporates a detenting manual override, mechanical spring reset, and a moderate corrosion resistance class (CRC 2) design that supports oil-lubricated operation. Submit your exact part number, quantity, and application requirements to receive an official quote for this Festo component.
View product details →
Festo
170864
Guided drive DFM-40-25-P-A-GF
The Festo part number 170864 is a double-acting industrial drive unit featuring a 40 mm piston diameter, a 25 mm stroke, and a yoke design with a plain-bearing guide. It operates within a pressure range of 1.5 bar to 10 bar using compressed air conforming to ISO 8573-1:2010 [7:4:4], supporting a maximum speed of 0.8 m/s and a maximum force Fy of 1227 N. Equipped with elastic cushioning rings at both ends, a 50 mm distance of the centre of gravity of the payload to the yoke plate, and position sensing via a proximity switch, this component functions across an ambient temperature range of -20 °C to 80 °C. Submit the exact part number, quantity, and application requirements for an RFQ quote.
View product details →
Festo
172949
On/off valve HEE-3/4-D-MIDI-230
The Festo 172949 is an electrical piston gate valve featuring a 3/2-way, closed, monostable valve function with piloted control and a soft sealing principle. It operates within a pressure range of 0.25 MPa to 1.6 MPa, delivers a normal nominal flow rate of 3800 l/min, and utilizes a 230 V AC coil with 100% duty cycle. This RoHS-compliant component includes a mechanical spring reset, detenting manual override, and positive overlap lap while requiring compressed air per ISO 8573-1:2010 [7:4:4] or inert gases with oil lubrication capability. Submit your exact part number, quantity, and application requirements to request a quote.
View product details →
Festo
170863
Guided drive DFM-32-200-P-A-GF
This Festo 170863 industrial component is a double-acting guide drive unit featuring a 32 mm piston diameter and a 200 mm stroke. It utilizes a plain-bearing guide and a yoke drive unit operating mode with elastic cushioning rings or pads at both ends, supporting an ambient temperature range of -20 °C to 80 °C and an operating pressure of 0.15 MPa to 1 MPa. Position sensing is achieved via proximity switch, while operating medium parameters follow compressed air standards per ISO 8573-1:2010 [7:4:4] with oil lubrication possible. Submit the exact part number, quantity, and application requirements for a formal quote.
View product details →
Festo
1708627
Adapter kit DHAA-D-H2-20/25-Q11-25
The Festo 1708627 industrial component features an anodized aluminum adapter plate, galvanized steel screws, and a steel centering pin with RoHS compliant materials. It supports any mounting position via a through-hole, screw, or centering sleeve configuration, while providing a corrosion resistance class of CRC 2 for moderate corrosion stress and VDMA24364-B1/B2-L LABS conformity. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →
Festo
172947
On/off valve HEE-3/4-D-MIDI-24
The Festo 172947 is an electrical piston gate valve featuring a 3/2-way closed, monostable valve function with soft sealing and piloted control. It operates within a pressure range of 0.25 MPa to 1.6 MPa, delivers a normal nominal flow rate of 3800 l/min, and utilizes a 24 V DC, 2.5 W coil with a 100% duty cycle. This RoHS-compliant component includes a mechanical spring reset, detenting manual override, positive overlap lap, and moderate corrosion resistance (CRC 2) while supporting compressed air and inert gases with optional oil lubrication. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →
Festo
170862
Guided drive DFM-32-160-P-A-GF
The Festo 170862 is a double-acting industrial drive unit featuring a 32 mm piston diameter, a 160 mm stroke, and a yoke drive operating mode with a plain-bearing guide. It operates with compressed air as per ISO 8573-1:2010 [7:4:4] across a pressure range of 0.15 MPa to 1 MPa, incorporating elastic cushioning rings at both ends and position sensing via proximity switch. The unit accommodates an ambient temperature range of -20 °C to 80 °C, a max speed of 0.8 m/s, and a center of gravity distance of the payload to the yoke plate xs of 50 mm. Submit the exact part number, quantity, and application requirements to request a quote for this component.
View product details →
Festo
172946
On/off valve HEE-1/2-D-MIDI-230
The Festo 172946 is an electrical piston gate valve featuring a soft sealing principle, positive overlap lap, and a 3/2-way, closed, monostable valve function with piloted control and a mechanical spring reset. Operating within a pressure range of 0.25 MPa to 1.6 MPa (2.5 bar to 16 bar), this component delivers a normal nominal flow rate of 3600 l/min, a C value of 17 l/sbar, and a b-value of 0.3, powered by a 230 V AC 50/60 Hz coil with a 100% duty cycle. It includes a detenting manual override, a non-throtttable exhaust air function, and moderate corrosion resistance (CRC 2), while accommodating compressed air to ISO 8573-1:2010 [7:4:4] or inert gases with oil lubrication permitted. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →
Festo
170861
Guided drive DFM-32-125-P-A-GF
The Festo 170861 is a double-acting industrial drive unit featuring a yoke structural design, a 32 mm piston diameter, and a 125 mm stroke with a plain-bearing guide. It operates on compressed air according to ISO 8573-1:2010 [7:4:4] within an operating pressure range of 0.15 MPa to 1 MPa (1.5 bar to 10 bar) and accommodates oil lubrication. Equipped with elastic cushioning rings or pads at both ends, this component delivers a max speed of 0.8 m/s, a max force Fy of 1227 N, and an impact energy of 0.4 Nm in the end positions. Position sensing is achieved via a proximity switch across an ambient temperature range of -20 °C to 80 °C, while meeting ISO 14644-1 class 6 cleanroom suitability and VDMA24364-B1/B2-L LABS conformity with a corrosion resistance class of 1. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →
Festo
170860
Guided drive DFM-32-100-P-A-GF
The Festo 170860 is a double-acting industrial drive unit featuring a 32 mm piston diameter, a 100 mm stroke, and a yoke operating mode with a plain-bearing guide. It operates on compressed air within a pressure range of 0.15 MPa to 1 MPa and supports a maximum speed of 0.8 m/s, utilizing elastic cushioning rings at both ends with an end-position impact energy of 0.4 Nm. Featuring a maximum force Fy of 1227 N and a centre of gravity distance of the payload to the yoke plate of 50 mm, the unit accommodates any mounting position and offers position sensing via proximity switch. Submit the exact part number, quantity, and application requirements to receive a formal quotation.
View product details →
Festo
172944
On/off valve HEE-1/2-D-MIDI-24
The Festo 172944 is an electrically actuated piston gate valve featuring a soft sealing principle and a 3/2-way, closed, monostable valve function with a positive overlap lap. Operating at pressures from 0.25 MPa to 1.6 MPa (2.5 bar to 16 bar), this piloted component delivers a normal nominal flow rate of 3600 l/min, a C value of 17 l/sbar, and a b-value of 0.3 using a 24 V DC, 2.5 W coil with 100% duty cycle. It utilizes mechanical spring reset, detenting manual override, and non-throttlable exhaust air, requiring compressed air per ISO 8573-1:2010 [7:4:4] or inert gases with optional oil lubrication, while offering a moderate corrosion resistance class (CRC 2) and RoHS-compliant materials. Submit the exact part number, quantity, and application requirements to receive a formal quotation.
View product details →
Festo
170859
Guided drive DFM-32-80-P-A-GF
The Festo 170859 is a double-acting industrial drive unit featuring a 32 mm piston diameter, an 80 mm stroke, and a yoke drive operating mode with a plain-bearing guide. It operates at pressures from 0.15 MPa to 1 MPa (1.5 bar to 10 bar) using compressed air conforming to ISO 8573-1:2010 [7:4:4], with a maximum speed of 0.8 m/s and elastic cushioning rings or pads at both ends. The unit accommodates any mounting position, achieves a maximum force Fy of 1227 N, and includes position sensing via proximity switch. Submit the exact part number, quantity, and application requirements for a quote.
View product details →
Festo
1704476
Motor flange EAMF-A-28B-28A
Engineered by Festo, this industrial component features a motor-in interface code of 28A and a coupling housing interface code of 28B with a total product weight of 34 g. It supports any mounting position and maintains RoHS-compliant material standards alongside VDMA24364-B2-L LABS conformity. The unit operates within an ambient temperature range of -10 °C to 60 °C, a storage temperature range of -25 °C to 60 °C, and 0 to 95% relative air humidity. Submit part number 1704476, quantity, and application requirements for a quote.
View product details →
Festo
172943
On/off valve HEE-3/8-D-MIDI-230
The Festo 172943 is an electrically actuated piston gate valve featuring a 3/2-way, closed, monostable valve function with piloted control and a mechanical spring reset. This soft-sealed component operates within a pressure range of 0.25 MPa to 1.6 MPa, delivering a normal nominal flow rate of 3200 l/min and a C value of 15.7 l/sbar with a positive overlap lap and non-throttleable exhaust air function. Powered by a 230 V AC (50/60 Hz) coil requiring 5.0 VA initial power and 3.7 VA holding power, the unit supports a 100% duty cycle and accepts compressed air or inert gases conforming to ISO 8573-1:2010 [7:4:4]. Submit your required quantity, exact part number, and application parameters to receive a quotation.
View product details →
Festo
170858
Guided drive DFM-32-50-P-A-GF
The Festo part number 170858 is a double-acting industrial drive unit featuring a yoke structural design, a 32 mm piston diameter, and a 50 mm stroke. It operates with compressed air as per ISO 8573-1:2010 [7:4:4] across an operating pressure range of 0.15 MPa to 1 MPa, incorporating elastic cushioning rings at both ends and a plain-bearing guide. Featuring a maximum speed of 0.8 m/s, a maximum force Fy of 1227 N, and position sensing via proximity switch, this component accommodates any mounting position within an ambient temperature range of -20 °C to 80 °C. Submit the exact part number, quantity, and application requirements to receive a formal quotation.
View product details →
Festo
170857
Guided drive DFM-32-40-P-A-GF
The Festo 170857 is a double-acting industrial drive unit featuring a 32 mm piston diameter, a 40 mm stroke, and a yoke drive operating mode with a 50 mm distance from the payload center of gravity to the yoke plate. Equipped with a plain-bearing guide, elastic cushioning rings or pads at both ends, and position sensing via proximity switch, this component operates within a pressure range of 0.15 MPa to 1 MPa and achieves a maximum speed of 0.8 m/s with a maximum force Fy of 1227 N. It functions across an ambient temperature range of -20 °C to 80 °C using compressed air as per ISO 8573-1:2010 [7:4:4], featuring Class 6 cleanroom suitability according to ISO 14644-1 and a corrosion resistance class of 1. Submit the exact part number, quantity, and application requirements for an official quote.
View product details →
