Festo
The Festo 162036 is a double-acting industrial guide drive unit featuring a 16 mm piston diameter, a 50 mm stroke, and a through piston rod design with a yoke operating mode. It operates on compressed air within a pressure range of 0.1 MPa to 1 MPa (1 bar to 10 bar) and delivers a theoretical force of 180 N in both retracting and advancing directions at 6 bar. This component utilizes elastic cushioning rings at both ends, accommodates an adjustable end position range of 10 mm, and integrates position sensing via proximity switch. Please submit the exact part number, quantity, and application requirements to receive a formal quotation.
View product details →
Festo
The Festo part number 162761 is a Maxi size series D industrial component featuring a filter regulator with a pressure gauge and a proportional standard oil mist lubricator. It offers an operating pressure range of 1 bar to 16 bar, a pressure regulation range of 0.5 bar to 7 bar, and a normal nominal flow rate of 8700 l/min normalized to DIN 1343. Designed with a 40 µm grade of filtration, an 80 cm³ max condensate volume, and a rotary knob with detent actuator lock, this unit operates within a temperature range of -10 °C to 60 °C. Submit the exact part number, quantity, and application requirements to receive a formal quote.
View product details →
Festo
The Festo 161309 is a double-acting industrial component featuring a 63 mm equivalent piston diameter, a 25 mm stroke, and an M16x1.5 piston rod thread. This unit utilizes an oval piston for torsion protection, providing a maximum angle of rotation of +/-0.4 degrees, a maximum torque for protection against rotation of 1.5 Nm, and elastic cushioning rings or pads at both ends. Operating within a pressure range of 1 bar to 10 bar and an ambient temperature range of -20 °C to 80 °C, it delivers a theoretical retracting force of 1682 N at 6 bar using compressed air as per ISO 8573-1:2010 [7:4:4]. Submit the exact part number, quantity, and application requirements for a quote.
View product details →
Festo
The Festo 162510 is an industrial component featuring a 2 mm Laval nozzle width, a 22 mm width dimension, and a closed muffler construction type for any mounting position. This unit delivers high vacuum ejector characteristics with a 40 µm grade of filtration, non-detenting manual override, and a closed valve function operating at 0.2 MPa to 0.8 MPa. Integrated functions include an electric ejector pulse valve, flow control valve, electric on-off valve, filter, and check valve, operating on a 21.6 V to 26.4 V DC voltage range at a 100% duty cycle with c UL us recognition. Submit the exact part number, quantity, and application requirements to receive a formal quotation.
View product details →
Festo
The Festo 162035 is a double-acting industrial drive unit featuring a 16 mm piston diameter, a 40 mm stroke, and a yoke operating mode with a through piston rod. It delivers a theoretical force of 180 N in both advancing and retracting directions at 6 bar, operating across a pressure range of 1 bar to 10 bar with compressed air conforming to ISO 8573-1:2010 [7:4:4]. Equipped with elastic cushioning rings at both ends, a recirculating ball bearing guide, and position sensing via proximity switch, this component functions in any mounting position within an ambient temperature range of -20 °C to 80 °C. Submit the exact part number, quantity, and application requirements to receive a formal quotation.
View product details →
Festo
This Festo D-series Maxi industrial component (part number 162760) combines a filter regulator with a pressure gauge and a proportional standard oil mist lubricator featuring a rotary knob with detent actuator lock. It operates within a pressure range of 1 bar to 16 bar, provides a pressure regulation range of 0.5 bar to 7 bar, and delivers a normal nominal flow rate of 8500 l/min for compressed air as per ISO 8573-1:2010 [-:-:-]. The unit includes a 40 µm grade of filtration, an 80 cm³ max. condensate volume with a manual rotating condensate drain, a metal bowl guard, and a vertical ±5° mounting position weighing 2390 g. Submit the exact part number, quantity, and application requirements for a quote.
View product details →
Festo
The Festo 161308 is a double-acting industrial component featuring a 63 mm equivalent piston diameter, a 10 mm stroke, and an M16x1.5 piston rod thread with a single-end configuration and an oval piston providing torsion protection up to 1.5 Nm and a rotation angle of +/- 0.4 degrees. Operating on compressed air according to ISO 8573-1:2010 [7:4:4] within a 1 bar to 10 bar pressure range and -20 °C to 80 °C ambient temperature, this unit achieves a theoretical retracting force of 1682 N at 6 bar while utilizing elastic cushioning rings at both ends for 0.7 J end-position impact energy. It incorporates position sensing via proximity switch, features a moderate corrosion resistance class rating of CRC 2 with VDMA24364-B1/B2-L LABS conformity, and allows for oil lubrication during operation. Submit your exact part number, quantity, and application requirements to request a quote for this Festo component.
View product details →
Festo
The Festo 162509 is an industrial component featuring a 1.4 mm Laval nozzle width, a 22 mm width dimension, and high vacuum ejector characteristics achieving a maximum vacuum of 85%. This unit integrates an electric ejector pulse valve, flow control valve, electric on-off valve, filter, and check valve, operating at a DC voltage range of 21.6 V to 26.4 V with a 100% duty cycle. It operates within a pressure range of 0.2 MPa to 0.8 MPa (2 bar to 8 bar, 29 psi to 116 psi) using compressed air as per ISO 8573-1:2010 [7:4:4] without oil lubrication, and holds a c UL us recognized certification. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →
Festo
The Festo 162034 is a double-acting industrial drive unit featuring a 16 mm piston diameter, a 25 mm stroke, and a recirculating ball bearing guide with a through piston rod. It operates at pressures from 1 bar to 10 bar using compressed air in accordance with ISO 8573-1:2010 [7:4:4], delivering a theoretical force of 180 N in both retracting and advancing directions at 6 bar. This structural design includes a yoke drive unit, elastic cushioning rings or pads at both ends with an end position impact energy of 0.15 Nm, an adjustable end position range of 10 mm, and position sensing via proximity switch. Designed for any mounting position within an ambient temperature range of -20 °C to 80 °C, the unit features a corrosion resistance class of CRC 0 and VDMA24364-B1/B2-L LABS conformity, while permitting operation with oil lubrication. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →
Festo
The Festo 162759 is a Midi-size industrial component from the D series, featuring a structural design that combines a filter regulator with a pressure gauge and a proportional standard oil mist lubricator. It offers an operating pressure range of 1 bar to 16 bar, a pressure regulation range of 0.5 bar to 7 bar, and a normal nominal flow rate of 2800 l/min for compressed air and inert gases. Equipped with a manual rotating condensate drain, a 40 µm grade of filtration, and a metal bowl guard, the unit operates within a medium temperature range of -10 °C to 60 °C in a vertical mounting position within ±5°. Submit the exact part number, quantity, and application requirements to receive a formal quotation.
View product details →
Festo
The Festo part number 161307 is a double-acting industrial component featuring a 63 mm equivalent piston diameter, an M16x1.5 piston rod thread, and an adjustable stroke from 1 mm to 320 mm with integrated elastic cushioning rings at both ends. Operating within a pressure range of 1 bar to 10 bar utilizing compressed air per ISO 8573-1:2010 [7:4:4], this unit provides a theoretical retracting force of 1682 N at 6 bar and incorporates an oval piston for torsion protection up to 1.5 Nm. Designed with heat-resistant seals supporting ambient temperatures up to 120 °C and a moderate corrosion resistance class of CRC 2, it permits oil lubrication and position sensing via proximity switch in any mounting position. Submit the exact part number, quantity, and application requirements to receive a formal quotation.
View product details →
Festo
The Festo part number 162033 is a double-acting industrial drive unit featuring a 16 mm piston diameter, a 10 mm stroke, and a through piston rod with a yoke operating mode. It incorporates elastic cushioning rings at both ends, a recirculating ball bearing guide, and position sensing via proximity switch, operating within a pressure range of 1 bar to 10 bar and an ambient temperature range of -20 °C to 80 °C. Delivering a theoretical force of 180 N both advancing and retracting at 6 bar, this unit operates with compressed air per ISO 8573-1:2010 [7:4:4] and permits optional oil lubrication. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →
Festo
The Festo part number 162508 is an industrial component featuring a 0.95 mm Laval nozzle, an 18 mm width dimension, a closed muffler construction type, and any mounting position with high vacuum ejector characteristics. It incorporates a non-detenting manual override, a 40 µm grade of filtration, and integrated functions including an electric ejector pulse valve, flow control valve, electric on-off valve, filter, and check valve with a closed valve function. Operating within a pressure range of 0.2 MPa to 0.8 MPa (2 bar to 8 bar, 29 psi to 116 psi) at a nominal operating pressure of 0.6 MPa (6 bar, 87 psi), it delivers a max vacuum of 85% and an air supply time of 2.04 s at nominal operating pressure with an ejector pulse. This c UL us-recognized (OL) component operates on a 21.6 V to 26.4 V DC operating voltage range with a 100% duty cycle using compressed air as per ISO 8573-1:2010 [7:4:4] without oil lubrication, maintaining a moderate corrosion stress rating (CRC 2) and VDMA24364-B1/B2-L LABS conformity. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →
Festo
The Festo 162758 is a Series D Midi industrial component featuring a structural design that combines a filter regulator with a pressure gauge and a proportional standard oil mist lubricator. It operates within a pressure range of 1 bar to 16 bar, provides a pressure regulation range of 0.5 bar to 7 bar, and delivers a normal nominal flow rate of 2800 l/min for compressed air as per ISO 8573-1:2010 [-:9:-] and inert gases. Equipment configuration includes a 40 µm grade of filtration, a manual rotating condensate drain with a maximum condensate volume of 43 cm³, a metal bowl guard, and a rotary knob actuator lock with detent for vertical ±5° mounting. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →
Festo
The Festo 161306 is a double-acting industrial component featuring a 63 mm equivalent piston diameter, an M16x1.5 piston rod thread, and a stroke range from 1 mm to 320 mm with through, hollow piston rod variants. Operating on compressed air per ISO 8573-1:2010 [7:4:4] within a pressure range of 1 bar to 10 bar, this unit utilizes an oval piston for torsion protection, elastic cushioning rings at both ends, and built-in position sensing via proximity switch. It delivers a theoretical retracting force of 1682 N at 6 bar while withstanding ambient temperatures between -20 °C and 80 °C and moderate corrosion stress corresponding to corrosion resistance class 2. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →
Festo
The Festo 162031 is a double-acting industrial drive unit featuring a yoke operating mode, a 16 mm piston diameter, and a 100 mm stroke with a 10 mm adjustable end position range. This component operates on compressed air within a pressure range of 1 bar to 10 bar, delivering a theoretical force of 242 N advancing and 180 N retracting at 6 bar. Equipped with recirculating ball bearing guides, elastic cushioning rings at both ends, and position sensing via proximity switch, the 636 g assembly functions in any mounting position across an ambient temperature range of -20 °C to 80 °C. Submit the exact part number, quantity, and application requirements to request a quote for this Festo component.
View product details →
Festo
The Festo part number 162507 is an industrial component featuring a 0.7 mm nominal width Laval nozzle, a 15 mm width dimension, a closed muffler construction type, and any mounting position. It delivers high vacuum ejector characteristics with a 40 µm grade of filtration, non-detenting manual override, and integrated functions including an electric ejector pulse valve, flow control valve, electric on-off valve, filter, and check valve, alongside a closed valve function. Operating within a pressure range of 0.15 MPa to 0.8 MPa (1.5 bar to 8 bar, 21.75 psi to 116 psi) and a maximum vacuum of 85%, the unit requires a nominal operating pressure of 0.6 MPa (6 bar, 87 psi) for an air supply time of 0.59 s with ejector pulse, utilizing a DC operating voltage range of 21.6 V to 26.4 V at a 100% duty cycle with c UL us - recognized (OL) certification. The operating medium is compressed air per ISO 8573-1:2010 [7:4:4] with oil lubrication not possible, a corrosion resistance class of CRC 2 for moderate corrosion stress, and LABS conformity according to VDMA24364-B1/B2-L. Submit the exact part number, quantity, and application requirements for a quote.
View product details →
Festo
The Festo 162757 is a Midi-size D-series industrial component featuring a structural design of a filter regulator with a pressure gauge and a proportional standard oil mist lubricator. It operates within a pressure range of 1 bar to 16 bar, provides a pressure regulation range of 0.5 bar to 7 bar, and delivers a normal nominal flow rate of 2000 l/min using compressed air or inert gases. Additional attributes include a 40 µm filtration grade, a manual rotating condensate drain with a 43 cm³ max condensate volume, a metal bowl guard, and a rotary knob with detent for the actuator lock. Submit the exact part number, quantity, and application requirements for a quote.
View product details →
Festo
The Festo 161305 is a double-acting industrial component featuring a 63 mm equivalent piston diameter, an M16x1.5 piston rod thread, and an adjustable stroke ranging from 1 mm to 320 mm with through piston rod variants. Operating within a pressure range of 1 bar to 10 bar utilizing compressed air per ISO 8573-1:2010 [7:4:4], the unit incorporates an oval piston for torsion protection, elastic cushioning rings at both ends, and position sensing via proximity switch. It delivers a theoretical retracting force of 1682 N at 6 bar while withstanding ambient temperatures between -20 °C and 80 °C under moderate corrosion stress (CRC 2). Submit the exact part number, quantity, and application requirements for a quote.
View product details →
Festo
This Festo industrial component features a 16 mm piston diameter, an 80 mm stroke, and a yoke drive unit operating mode with an adjustable end position range of 10 mm. Operating on compressed air according to ISO 8573-1:2010 [7:4:4] within a pressure range of 1 bar to 10 bar, the double-acting unit delivers a theoretical force of 180 N retracting and 242 N advancing at 6 bar. The structural design incorporates a recirculating ball bearing guide, elastic cushioning rings at both ends, and position sensing via proximity switch across an ambient temperature range of -20 °C to 80 °C. Submit the exact part number, quantity, and application requirements to request a formal quote.
View product details →
