Industrial sourcing catalog
Browse verified product records and request commercial availability, lead time and technical documentation.
Festo
The Festo 1492348 is a 2/2-way, closed, monostable industrial component featuring a force pilot-operated diaphragm valve design with soft sealing and a G1 1/2 in-line mounting fitting connection. It operates via electrical actuation using a 230 V AC (50/60 Hz) coil with 30.0 VA initial and holding power, accommodating a medium pressure range of 0 bar to 10 bar and a nominal pressure PN of 40. Compatible media include compressed air as per ISO 8573-1:2010 [7:-:-], inert gas, mineral oil, water, and neutral liquids directed through a 40 mm nominal width and non-reversible flow path. Submit the exact part number, quantity, and application requirements to receive a formal quotation.
View product details →
Festo
The Festo mounting kit WSR-25-J is an industrial component corresponding to official Festo EN-US data sheet specification text LABS (PWIS) conformity VDMA24364-B2-L 6/5/26. This hardware features verified LABS (PWIS) conformity according to VDMA24364-B2-L. Submit the exact part number, quantity, and application requirements to request a formal quote.
View product details →
Festo
The Festo 14921 is a double-acting industrial component featuring a 50 mm piston diameter, an M16x1,5 piston rod thread with a male end, and a variable stroke ranging from 1 to 2,000 mm. Built with a piston and piston rod design conforming to ISO 6431, this unit operates at pressures between 0.5 and 12 bar using dried compressed air and incorporates adjustable pneumatic cushioning at both ends with heat-resistant seals rated up to 120 °C. It delivers a theoretical force of 1,131 N on the advance stroke and 924 N on the return stroke at 6 bar, while supporting position detection via proximity sensors in any assembly position. Submit the exact part number, quantity, and application requirements to receive a formal quotation for this component.
View product details →
Festo
The Festo 1489991 is a pilot-controlled piston poppet valve featuring a 2/2-way, closed, monostable function with soft sealing and a 13 mm nominal width. Configured for electrical actuation with a 230 V AC coil operating at 50/60 Hz, this in-line mounted component includes a 3/8 NPT fitting connection and a Type A rectangular electrical connection per EN 175301-803. It handles compressed air, inert gas, and neutral liquids with a non-reversible flow direction, a 40 PN nominal pressure, and a 100% duty cycle. Submit the exact part number, quantity, and application requirements to receive a formal quotation.
View product details →
Festo
The Festo 1492347 is a force pilot-operated 2/2-way closed monostable diaphragm valve featuring a soft sealing principle and a 40 mm nominal width. This electrical component utilizes an in-line installation design with a G1 1/4 fitting connection, a Type A plug electrical connection per EN 175301-803, and an upright magnet mounting position. It operates with a 230 V AC 50/60 Hz coil requiring 30.0 VA initial and holding power, supporting a medium pressure range of 0 bar to 10 bar and a nominal fitting pressure PN of 40 for compressed air, inert gas, mineral oil, water, and neutral liquids. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →
Festo
The Festo Microswitch SR-3-E-SW is an industrial component featuring a CE symbol according to the EU low voltage guideline, as documented in the official Festo EN-US data sheet. Please submit the exact part number, quantity, and application requirements to request a quote.
View product details →
Festo
The Festo 1492097 is a 2/2-way closed monostable industrial component featuring a directly actuated poppet valve design with soft sealing and a 6 mm nominal width. Powered by a 230 V AC coil at 50/60 Hz with class F insulation and a 100% duty cycle, this unit operates with a non-reversible flow direction, 1/4 NPT in-line installation, and a nominal pressure rating of 100 PN for compressed air, inert gas, mineral oil, water, and neutral liquids. Submit the exact part number, quantity, and application requirements to receive a formal quotation.
View product details →
Festo
The Festo part number 1489990 is a pilot-controlled piston poppet valve featuring a 2/2-way closed monostable function and soft sealing principle for in-line installation with 1/4 NPT fitting connections. This electrical actuator operates on a 230 V AC 50/60 Hz coil with class H insulation, supporting a 100% duty cycle, a nominal pressure PN of 40, and a 0.5 bar differential pressure for compressed air, inert gas, and neutral liquids. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →
Festo
The Festo mounting kit WSR-25 is an industrial component detailed in the official Festo EN-US data sheet under the 6/5/26 specification text. This assembly adheres to LABS (PWIS) conformity standard VDMA24364-B2-L. Submit the exact part number, quantity, and application requirements to receive a formal quotation for this Festo component.
View product details →
Festo
The Festo part number 1492346 is an electrical, force pilot-operated diaphragm valve featuring a soft sealing principle and a 2/2-way, closed, monostable valve function with a 27.5 mm nominal width. Designed for in-line installation with a G1 fitting connection and a magnet upright mounting position, this non-reversible component operates with a nominal pressure PN of 40 and a medium pressure range of 0 bar to 6 bar. It utilizes a Type A plug electrical connection as per EN 175301-803 in a rectangular design, powered by a 230 V AC (50/60 Hz) coil with an initial power of 18.0 VA and a holding power of 15.0 VA, accommodating permissible voltage fluctuations of +/- 10%. Compatible media include compressed air as per ISO 8573-1:2010 [7:-:-], inert gas, mineral oil, water, neutral liquids, and other flow media upon request, with zero manual override. Submit the exact part number, quantity, and application requirements to receive a formal quotation.
View product details →
Festo
The Festo 1492096 is a directly actuated poppet valve featuring a soft sealing principle, a nominal width of 5 mm, and a 2/2-way closed, monostable valve function with a mechanical spring reset method. Designed for in-line installation with a 1/4 NPT fitting connection and a non-reversible flow direction, this electrical component operates on 230 V AC (50/60 Hz) with an insulation class F coil, an initial power of 18.0 VA, a holding power of 15.0 VA, and a 100% duty cycle. It accommodates compressed air, inert gas, mineral oil, water, neutral liquids, and other flow media on request, supporting a nominal pressure PN of 100 and a differential pressure of 0 bar across any mounting position. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →
Festo
The Festo part number 1478121 is an industrial component featuring a size 16 structural design with a positively driven motion sequence and position sensing via proximity switch. Operating at 3 bar to 6 bar using compressed air as per ISO 8573-1:2010 [7:-:-], this 340 g unit achieves a repetition accuracy of ±0.02 mm, a maximum pivot time of 150 ms, a max impact velocity of 0.8 m/s, and a max stop force of 1100 N. Constructed with a wrought aluminum alloy housing and PU seals offering CRC 1 corrosion resistance, it utilizes M5 pneumatic connections and mounts via through-hole and centering sleeve in any position within an ambient temperature range of 0 °C to 60 °C. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →
Festo
The Festo 1489989 is a pilot-controlled piston poppet valve featuring a 2/2-way closed monostable function, soft sealing principle, and a 25 mm nominal width with a 1 NPT fitting connection. Engineered for in-line installation with a preferred coil mounting position on top, this electrical actuation component operates on 110 V AC (50/60 Hz) with Class H insulation, a 100% duty cycle, and an EN 175301-803 Type A plug connection. It handles compressed air, inert gases, and neutral liquids with a 40 PN nominal pressure, non-reversible flow direction, and piloted control requiring a 0.5 bar differential pressure. Submit the exact part number, quantity, and application requirements to receive a formal quotation.
View product details →
Festo
The Festo 1492345 is an electrical diaphragm valve featuring a force-pilot-operated structural design and a soft sealing principle for in-line installation with a G3/4 fitting connection. This 2/2-way, closed, monostable industrial component operates with a nominal width of 27.5 mm, a nominal pressure PN of 40, and a medium pressure range of 0 bar to 6 bar. It accepts a 230 V AC 50/60 Hz electrical connection via a rectangular Type A plug as per EN 175301-803, utilizing an initial power of 18.0 VA and holding power of 15.0 VA with permissible voltage fluctuations of +/- 10%. Submit the exact part number, quantity, and application requirements to receive a formal quotation.
View product details →
Festo
The Festo part number 1492095 is a directly actuated poppet valve featuring a soft sealing principle and a 2/2-way, closed, monostable valve function with a nominal width of 4 mm and a 1/4 NPT fitting connection. This electrical component operates with a mechanical spring reset method, a 100% duty cycle, and a 230 V AC coil at 50/60 Hz, accommodating media such as compressed air, inert gas, mineral oil, water, and neutral liquids up to a nominal pressure of 100 PN. Designed for in-line installation in any mounting position, it utilizes an EN 175301-803 Type A rectangular plug connection with class F insulation and handles a pressure difference of 0 bar. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →
Festo
The Festo part number 14770 is an industrial component featuring a nominal width of 4.9 mm and a die-cast zinc housing with RoHS compliance. This unit operates within a temperature range of 0 °C to 60 °C and an operating pressure of -0.95 bar to 10 bar across the entire temperature range for compressed air meeting ISO 8573-1:2010 [7:-:-], where oil lubrication operation is possible and required for further use. It includes a pneumatic connection 1 designed for pneumatic tubing with an outside diameter of 8 mm and maintains VDMA24364-B1/B2-L LABS conformity. Submit the exact part number, quantity, and application requirements for a quote.
View product details →
Festo
The Festo 1489988 is a pilot-controlled piston poppet valve featuring a 2/2-way, closed, monostable function with soft sealing and a 25 mm nominal width. This electrical component utilizes in-line installation with a 3/4 NPT fitting connection, a Type A plug electrical connection per EN 175301-803, and operates on a 110 V AC 50/60 Hz coil with class H insulation and a 100% duty cycle. It accommodates compressed air conforming to ISO 8573-1:2010 [7:4:4], inert gas, and neutral liquids, supporting a nominal pressure PN of 40, a 0.5 bar differential pressure, and non-reversible flow direction with the coil positioned on top. Submit the exact part number, quantity, and application requirements to request a formal quote for this component.
View product details →
Festo
The Festo 1492344 is an electrically actuated diaphragm valve featuring a force pilot-operated structural design, soft sealing principle, and G1/2 fitting connection for in-line installation with upright magnet mounting. This 2/2-way, closed, monostable industrial component operates with a 13.5 mm nominal width, non-reversible flow direction, 40 PN nominal pressure, and a medium pressure range of 0 bar to 10 bar. It functions with a 230 V AC (50/60 Hz) coil drawing 18.0 VA initial power and 15.0 VA holding power, supporting permissible voltage fluctuations of +/- 10% across compressed air, inert gas, mineral oil, water, and neutral liquids. Submit the exact part number, quantity, and application requirements to receive a formal quotation.
View product details →
Festo
The Festo 1492094 is a directly actuated poppet valve featuring a soft sealing principle, a 3 mm nominal width, and a 2/2-way closed, monostable valve function with a mechanical spring reset method. This electrical component supports in-line installation in any mounting position with 1/4 NPT fitting connections and accepts a 230 V AC 50/60 Hz coil with class F insulation, a 100% duty cycle, and permissible voltage fluctuations of +/- 10%. It handles compressed air, inert gas, mineral oil, water, and neutral liquids with a nominal pressure PN of 100 and zero differential pressure. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →
Festo
The Festo 14769 is an industrial component featuring a die-cast zinc housing with a nominal width of 2.9 mm and a pneumatic connection 1 designed for pneumatic tubing with an outside diameter of 6 mm. This RoHS-compliant part operates with compressed air as per ISO 8573-1:2010 [7:-:-] across an operating pressure range of -0.95 bar to 10 bar and an ambient temperature range of 0 °C to 60 °C. Operation with oil lubrication is possible and required for further use, while the unit conforms to VDMA24364-B1/B2-L LABS (PWIS) standards. Submit the exact part number, quantity, and application requirements to receive a quote.
View product details →
