Industrial sourcing catalog
Browse verified product records and request commercial availability, lead time and technical documentation.
Festo
The Festo 1489987 is a pilot-controlled piston poppet industrial component featuring a 2/2-way, closed, monostable valve function with a nominal width of 13 mm and soft sealing. Designed for in-line installation with 1/2 NPT fitting connections and a coil preferably mounted on top, this electrically actuated valve operates on 110 V AC at 50/60 Hz with a 100% duty cycle, class H insulation, and non-reversible flow for compressed air, inert gas, and neutral liquids. Submit the exact part number, quantity, and application requirements to receive a formal quotation.
View product details →
Festo
The Festo 1492343 is an electrically actuated, force pilot-operated diaphragm valve featuring a soft sealing principle and a 2/2-way, closed, monostable valve function with a 13.5 mm nominal width. Configured for in-line installation with a G3/8 fitting connection and upright magnet mounting position, this component operates with a non-reversible flow direction, a PN 40 nominal pressure, and a medium pressure range of 0 bar to 10 bar (0 psi to 145 psi). It is compatible with compressed air meeting ISO 8573-1:2010 [7:-:-], inert gas, mineral oil, water, and neutral liquids, utilizing a Type A plug electrical connection per EN 175301-803 operating on 230 V AC (50/60 Hz) with an initial power of 18.0 VA and holding power of 15.0 VA. Submit your exact part number, quantity, and application requirements to request a quote for this component.
View product details →
Festo
The Festo 14768 is a die-cast zinc industrial component featuring a nominal width of 2 mm and a pneumatic connection 1 designed for 4 mm outside diameter pneumatic tubing. This RoHS compliant part operates with compressed air as per ISO 8573-1:2010 [7:-:-] across an operating pressure range of -0.95 bar to 10 bar and an ambient temperature range of 0 °C to 60 °C. It accommodates VDMA24364-B1/B2-L LABS conformity and permits operation with oil lubrication, which is required for further use. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →
Festo
The Festo 1492093 is an electrically actuated, directly operated poppet valve featuring a soft sealing principle and a 2.5 mm nominal width in a 2/2-way, closed, monostable configuration with a non-reversible flow direction. Designed for in-line installation with a 1/4 NPT fitting connection and a 100 bar nominal pressure rating, it operates on a 230 V AC 50/60 Hz coil with class F insulation, a 100% duty cycle, and mechanical spring reset. This component accommodates compressed air, inert gas, mineral oil, water, and neutral liquids, functioning with a 0 bar pressure difference across any mounting position. Submit the exact part number, quantity, and application requirements to receive a formal quotation.
View product details →
Festo
The Festo part number 1476585 is an electric actuator featuring a ball screw drive and a size 16 stepper motor operating on a nominal DC voltage of 24 V at 1.4 A. This component provides a stroke range of 50 mm to 200 mm, a repetition accuracy of ±0.02 mm, a 100% duty cycle, and insulation protection class B, with structural compliance including c UL us recognition and RCM certification. Submit the exact part number, quantity, and application requirements to receive a formal quotation.
View product details →
Festo
The Festo 1489986 is an electrical, pilot-controlled piston poppet valve featuring a soft sealing principle, a 13 mm nominal width, and a 2/2-way, closed, monostable valve function configured for in-line installation with a 3/8 NPT fitting connection. Powered by a class H insulated 110 V AC (50/60 Hz) coil with 100% duty cycle, this non-reversible component operates with a 0.05 MPa (7.25 psi / 0.5 bar) differential pressure and a nominal fitting pressure PN of 40 using compressed air, inert gas, or neutral liquids. Submit the exact part number, quantity, and application requirements to request a quote for this item.
View product details →
Festo
The Festo 1492342 is an electrically actuated, force pilot-operated diaphragm valve featuring a soft sealing principle and a 2/2-way closed, monostable valve function with a 13.5 mm nominal width. Designed for in-line installation with an upright magnet mounting position and G1/4 fitting connections, this component operates with a 0 bar differential pressure and a medium pressure range of 0 bar to 10 bar (0 psi to 145 psi) at a nominal pressure PN of 40. It accommodates compressed air conforming to ISO 8573-1:2010 [7:-:-], inert gas, mineral oil, water, and neutral liquids through a non-reversible flow direction, utilizing an EN 175301-803 Type A rectangular plug electrical connection powered by 230 V AC (50/60 Hz) with an initial power of 18.0 VA and holding power of 15.0 VA. Submit your exact part number, quantity, and application requirements to request a quote for this industrial component.
View product details →
Festo
The Festo 1492092 is a directly actuated poppet valve featuring a 2/2-way, closed, monostable function with a soft sealing principle and a 2 mm nominal width. This electrical component utilizes an in-line installation with a 1/4 NPT fitting connection, a Type A plug electrical connection as per EN 175301-803, and supports any mounting position. It operates on 230 V AC (50/60 Hz) with Class F insulation, a 100% duty cycle, and mechanical spring reset, handling compressed air, inert gas, mineral oil, water, and neutral liquids at a nominal pressure PN of 100. Submit the exact part number, quantity, and application requirements to receive a formal quotation for this industrial component.
View product details →
Festo
The Festo 1476528 is an electric actuator with a ball screw drive featuring a size 16 format, a 200 mm stroke, and an 8 mm screw diameter with an 8 mm/U spindle pitch. This component includes a stepper motor, an external M6 piston rod thread, a plain-bearing guide for torsion protection, and an incremental optical rotor position sensor with an RS422 TTL interface. Configured for any mounting position, the unit delivers a 1.8-degree full step angle, a maximum acceleration of 10 m/s², and a piston rod rotation angle of plus or minus 2 degrees. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →
Festo
The Festo 1489985 is an electrically actuated, pilot-controlled piston poppet valve featuring a soft sealing principle and a 13 mm nominal width in a 2/2-way, closed, monostable configuration with in-line installation via 1/4 NPT fitting connections. It operates with a non-reversible flow direction for compressed air as per ISO 8573-1:2010 [7:4:4], inert gas, and neutral liquids, supporting a nominal pressure PN of 40, a pressure difference of 0.05 MPa (7.25 psi), and a differential pressure of 0.5 bar. Electrical actuation is managed through a Type A plug connection conforming to EN 175301-803 for 110 V AC at 50/60 Hz with class H insulation, a 100% duty cycle, and initial and holding power ratings of 10.5 VA and 8.0 VA, respectively. Submit the exact part number, quantity, and application requirements to receive a formal quotation.
View product details →
Festo
The Festo part number 1492091 is a directly actuated poppet valve featuring a 2/2-way, closed, monostable valve function with soft sealing and a 1.5 mm nominal width. This electrical component utilizes an EN 175301-803 Type A rectangular plug connection, operates on 230 V AC at 50/60 Hz with 100% duty cycle, and handles a 100 PN nominal pressure with zero differential pressure. It supports in-line installation in any mounting position via 1/4 NPT fitting connections, employing a mechanical spring reset for non-reversible flow of compressed air, inert gas, mineral oil, water, and neutral liquids. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →
Festo
The Festo 1492341 is a force pilot-operated diaphragm valve featuring a soft sealing principle and a 2/2-way, closed, monostable valve function with a 50 mm nominal width. This electrical component utilizes an in-line installation mounting type with a G2 fitting connection, a non-reversible flow direction, and an upright magnet mounting position without a manual override. It operates with a nominal pressure fitting PN of 40, a 0 bar differential pressure, and a medium pressure range of 0 bar to 6 bar using compressed air, inert gas, mineral oil, water, or neutral liquids. Electrical actuation is handled via an EN 175301-803 Type A rectangular plug connection and a 230 V AC coil requiring 30.0 VA at 50/60 Hz with permissible voltage fluctuations of +/- 10%. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →
Festo
The Festo 1476526 is an electric actuator featuring a ball screw drive with an 8 mm screw diameter, an 8 mm/U spindle pitch, and a size 16 design providing a 150 mm stroke with zero stroke reserve. This component integrates a stepper motor with a 1.8-degree full step angle, a ±5% step angle tolerance, an optical incremental encoder with an RS422 TTL A/B channels and zero index interface, and a plain-bearing guide ensuring torsion protection with a maximum piston rod rotation angle of ±2 degrees. The unit includes an M6 external thread piston rod end, a 0.1 mm reversing backlash, and an overall maximum acceleration of 10 m/s² while supporting any mounting position. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →
Festo
The Festo 1489984 is an electrical, pilot-controlled piston poppet valve featuring a 2/2-way closed monostable function with soft sealing and non-reversible flow direction. This in-line installation component includes a 1 NPT fitting connection, a 25 mm nominal width, and operates with a nominal pressure PN of 40 for compressed air, inert gas, neutral liquids, and other flow media on request. Driven by a piloted control type with a Type A EN 175301-803 electrical connection, the Class H coil requires 110 V AC at 50/60 Hz with 100% duty cycle and permissible voltage fluctuations of +/- 10%. Submit the exact part number, quantity, and application requirements to request a quote for this industrial component.
View product details →
Festo
The Festo 1492090 is a directly actuated poppet valve featuring a 2/2-way, closed, monostable function with soft sealing and a nominal width of 1 mm. This electrical component utilizes an in-line installation design with 1/4 NPT fitting connections, a mechanical spring reset method, and operates with a 230 V AC coil at 50/60 Hz with class F insulation and a 100% duty cycle. Compatible with compressed air, inert gas, mineral oil, water, and neutral liquids, it handles a nominal pressure of 100 PN and a pressure difference of 0 bar, 0 MPa, or 0 psi in a non-reversible flow direction. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →
Festo
The Festo 1492340 is a force pilot-operated diaphragm valve featuring a soft sealing principle and a 2/2-way, closed, monostable valve function with a 40 mm nominal width. This electrical component utilizes an in-line installation design with a G1 1/2 fitting connection, a non-reversible flow direction, and an upright magnet mounting position. It operates with a 230 V AC coil drawing 30.0 VA at 50/60 Hz within a permissible voltage fluctuation of +/- 10%, accommodating a medium pressure range from 0 bar to 10 bar across compressed air, inert gas, mineral oil, water, and neutral liquids. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →
Festo
The Festo 1476524 is an electric actuator featuring a ball screw drive with a size 16 format, a 100 mm stroke, and an 8 mm screw diameter with an 8 mm/U spindle pitch. This component includes a stepper motor, an external M6 piston rod thread, a plain-bearing guide for torsion protection, and an incremental optical rotor position sensor with an RS422 TTL A/B channels and zero index interface. Operating with a 1.8 degree full step angle at a ±5% tolerance, 0.1 mm reversing backlash, and a maximum acceleration of 10 m/s², the unit permits any mounting position and a maximum piston rod rotation angle of ±2 degrees. Submit the exact part number, quantity, and application requirements for a quote.
View product details →
Festo
The Festo 1489983 is a pilot-controlled piston poppet valve featuring a soft sealing principle, 25 mm nominal width, and a 2/2-way closed monostable valve function with non-reversible flow direction. Designed for in-line installation with 3/4 NPT fitting connections, it operates on a 110 V AC 50/60 Hz electrical supply through a Type A plug connection conforming to EN 175301-803. This component handles compressed air, inert gas, and neutral liquids with a nominal pressure PN of 40 and a 100% duty cycle. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →
Festo
Engineered with a positively driven motion sequence, the Festo industrial component part number 1492072 features a size 10 wrought aluminum alloy housing with PU seals and operates at pressures between 3 bar and 6 bar using compressed air as per ISO 8573-1:2010 [7:-:-]. This 154 g unit achieves a repetition accuracy of ±0.02 mm, a maximum impact velocity of 0.8 m/s, a maximum pivot time of 150 ms, and a maximum stop force of 500 N, supporting mounting in any position via through-hole and centering sleeve. Submit the exact part number, quantity, and application requirements to receive a formal quote.
View product details →
Festo
The Festo 1492339 is an electrically actuated, force pilot-operated diaphragm valve featuring a soft sealing principle, a G1 1/4 fitting connection, and a 40 mm nominal width in a 2/2-way closed, monostable configuration. It operates with a non-reversible flow direction, supports medium pressures from 0 bar to 10 bar (0 psi to 145 psi) with a 0 bar differential pressure, and is compatible with compressed air meeting ISO 8573-1:2010 [7:-:-], inert gas, mineral oil, water, and neutral liquids. Powered by a 230 V AC (50/60 Hz) coil requiring 30.0 VA initial and holding power with permissible voltage fluctuations of +/- 10%, the unit connects via a rectangular Type A plug as per EN 175301-803 for upright magnet mounting. Submit the exact part number, quantity, and application requirements for a formal quote.
View product details →
