Festo
2876444
Hinge cylinder DFAW-50-50-CRB6-PPSA
This Festo industrial component, part number 2876444, is a double-acting cylinder featuring a 50 mm piston diameter, a 50 mm stroke, and integrated flow control valves on both sides for speed regulation. The design incorporates a piston, a piston rod with a male threaded rod clevis, a swivel mounting on the bearing cap, and a cylinder barrel with self-adjusting pneumatic end-position cushioning (PPS) offering a 24 mm cushioning length. Operating within a working pressure range of 2 to 10 bar using compressed air meeting ISO8573-1:2010 [7:4:4] standards, it delivers a theoretical force of 1,178 N on the advance stroke and 990 N on the return stroke at 6 bar. Suitable for any assembly position and equipped for position detection via proximity sensors, the unit operates in ambient temperatures from -10 to 60 °C with a CRC corrosion resistance classification of 0 and a moving mass of 653 g at 0 mm stroke. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →
