Industrial sourcing catalog
Search by Manufacturer Part Number
Browse verified product records and request commercial availability, lead time and technical documentation.
Festo
574464
Manifold rail VABM-L1-18S-G38-12
The Festo 574464 is an industrial component featuring a wrought aluminum alloy manifold rail with a width dimension of 19 mm, a product weight of 936 g, and G3/8 pneumatic connections 1, 3, and 5. This RoHS compliant part accommodates a maximum of 16 valve positions, operates within a pressure range of -0.09 MPa to 1 MPa (-0.9 bar to 10 bar), and meets ISO 14644-1 Class 5 cleanroom standards with CRC 2 moderate corrosion stress resistance. It holds RCM compliance and c UL us - recognized (OL) certifications, features VDMA24364-B1/B2-L LABS conformity, and is suitable for battery production with reduced Cu/Zn/Ni values (F1a) while requiring maximum tightening torques of 1.5 Nm for DIN rail mounting, 1.18 Nm for valve mounting, and 3 Nm for wall mounting. Submit the exact part number, quantity, and application requirements to receive a formal quotation.
View product details →
Festo
575605
Air solenoid valve VUVS-L30-M52-MZD-G38-F8-1C1
The Festo 575605 is an electrical 31 mm piston gate valve featuring a 5/2-way monostable function, a normal nominal flow rate of 2300 l/min, and G3/8 pneumatic working ports. It operates on 24V DC with an operating pressure range of -0.09 MPa to 1 MPa (-0.9 bar to 10 bar) and includes an adjustable exhaust air function, mechanical spring reset, and external pilot air supply. Certified as c UL us-recognized (OL) with an IP65 degree of protection using a plug socket, the unit supports any mounting position, reversible flow direction, and both detenting and non-detenting manual override. Submit the exact part number, quantity, and application requirements to receive a formal quotation for this component.
View product details →
Festo
574104
Electric cylinder ESBF-BS-80-100-5P
The Festo 574104 is an electric cylinder with a ball screw structural design based on the ISO 15552 norm, featuring an 80 size, a 100 mm working stroke, and a 100 mm stroke. It operates with a servo motor, a 32 mm screw diameter, a 5 mm/U spindle pitch, an M20x1.5 piston rod thread with external thread, and a plain bearing-guide providing a torsion protection and a maximum angle of rotation of the piston rod of plus or minus 0.5 degrees. This unit achieves a maximum speed of 0.25 m/s, a maximum rotational speed of 2530 rpm, a maximum acceleration of 5 m/s squared, a 30 micrometer reversing backlash, and a repetition accuracy of plus or minus 0.01 mm with position sensing via proximity switch and any mounting position. Request a quote by submitting the exact part number, quantity, and application requirements.
View product details →
Festo
574463
Manifold rail VABM-L1-18S-G38-10
The Festo 574463 is an industrial component featuring a wrought aluminum alloy manifold rail with a 19 mm width and a product weight of 794 g, supporting a maximum of 16 valve positions. It operates within a pressure range of -0.09 MPa to 1 MPa (-0.9 bar to 10 bar) and incorporates G3/8 pneumatic connections 1, 3, and 5 alongside specified tightening torques of 1.5 Nm for DIN rail mounting, 1.18 Nm for valve mounting, and 3 Nm for wall mounting. Certified with the RCM compliance mark and c UL us recognition (OL), this RoHS-compliant unit exhibits a corrosion resistance class (CRC) of 2, VDMA24364-B1/B2-L LABS conformity, ISO 14644-1 Class 5 cleanroom suitability, and suitability for Li-ion battery production with reduced Cu/Zn/Ni values (F1a). Submit the exact part number, quantity, and application requirements to receive a formal quote.
View product details →
Festo
575492
Air solenoid valve VUVS-L25-M32U-MD-G14-F8-1C1
The Festo 575492 is a 26.5 mm electrical piston gate valve featuring a 3/2-way monostable open valve function with an internal pilot air supply port and non-reversible flow direction. Delivering a normal nominal flow rate of 1000 l/min through G1/4 pneumatic working ports, this component operates on a 24V DC operating voltage across a 0.25 MPa to 1 MPa operating pressure range. The unit incorporates a soft sealing principle, mechanical spring reset method, adjustable exhaust air function, positive overlap lap, nominal width of 6.3 mm, and detenting or non-detenting manual override, while achieving an IP65 degree of protection with a plug socket per IEC 60529 and c UL us recognition. Request a quote today by submitting your exact part number, quantity, and application requirements.
View product details →SMC
EX245-DX1
SMC EX245-DX1 — Industrial Component
The SMC EX245-DX1 is an industrial component manufactured by SMC. Submit the exact part number, quantity, and application requirements for a quote.
View product details →
Festo
575604
Air solenoid valve VUVS-L30-M52-MD-G38-F8-1C1
The Festo 575604 is an electrical 5/2-way monostable industrial component featuring a 31 mm valve size and a piston gate valve structural design with a soft sealing principle. This piloted valve operates on 24V DC within an operating pressure range of 0.25 MPa to 1 MPa (2.5 bar to 10 bar), delivering a normal nominal flow rate of 2300 l/min through G3/8 pneumatic working ports. It includes a mechanical spring reset method, internal pilot air supply, adjustable exhaust air function, positive overlap lap, and both detenting and non-detenting manual override capabilities while achieving an IP65 degree of protection with a plug socket in any mounting position according to IEC 60529 and c UL us recognition (OL). Submit the exact part number, quantity, and application requirements to receive a formal quote.
View product details →
Festo
574462
Manifold rail VABM-L1-18S-G38-9
Engineered by Festo, the part number 574462 is an industrial component featuring a 19 mm width dimension, a wrought aluminum alloy manifold rail, and a product weight of 723 g supporting a maximum of 16 valve positions. Operating within a pressure range of -0.09 MPa to 1 MPa (-0.9 bar to 10 bar), the unit incorporates G3/8 pneumatic connections for ports 1, 3, and 5 alongside specific tightening torques of 1.5 Nm for DIN rail mounting, 1.18 Nm for valve mounting, and 3 Nm for wall mounting. Certified with the RCM compliance mark and c UL us recognition (OL), it achieves corrosion resistance class CRC 2, VDMA24364-B1/B2-L LABS conformity, ISO 14644-1 Class 5 cleanroom suitability, and RoHS compliance with reduced Cu/Zn/Ni values (F1a) for Li-ion battery production. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →
Festo
574103
Electric cylinder ESBF-BS-63-400-25P
The Festo 574103 is an electric cylinder with a ball screw based on the ISO 15552 norm, featuring a size 63 design and a working stroke of 400 mm. This component integrates a 25 mm screw diameter, a 25 mm/U spindle pitch, an M16x1.5 external piston rod end thread, and a plain bearing-guide providing a maximum angle of rotation of +/- 0.4 degrees and 40 µm reversing backlash. Operating with a servo motor, it achieves a maximum speed of 1.35 m/s, a maximum rotational speed of 3260 rpm, a maximum acceleration of 25 m/s², and a repetition accuracy of ±0.01 mm with position sensing via a proximity switch in any mounting position. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →
Danfoss Industrieautomatik
032U2019
Danfoss Industrieautomatik 032U2019 — Spare Parts Kit
The Danfoss Industrieautomatik part number 032U2019, also identified as manufacturer model ERSATZTEILSATZ EV210B 25 / 032U2019 | 278340, is an industrial component designed for specific valve maintenance applications. Please submit the exact part number, quantity, and application requirements to receive a formal quotation.
View product details →
Festo
575491
Air solenoid valve VUVS-L25-M32U-AZD-G14-F8-1C1
The Festo part number 575491 is a 3/2-way monostable open industrial component featuring an electrical actuation type and a piston gate valve structural design with a 26.5 mm valve size and a 6.3 mm nominal width. This unit delivers a normal nominal flow rate of 1000 l/min through G1/4 pneumatic working ports, operates on 24V DC at pressures ranging from -0.09 MPa to 1 MPa, and includes a pneumatic spring reset method with adjustable exhaust air function, external pilot air supply port, and reversible flow direction. Equipped with soft sealing, positive overlap, and a detenting or non-detenting manual override, the assembly provides IP65 protection with a plug socket and carries c UL us recognition certification for any mounting position. Submit the exact part number, quantity, and application requirements to receive a formal quotation.
View product details →
Festo
575603
Air solenoid valve VUVS-L30-M52-MZD-G38-F8
The Festo 575603 is a 31 mm electrical 5/2-way monostable piston gate valve featuring a piloted type of control and an external pilot air supply port. This component delivers a normal nominal flow rate of 2300 l/min through G3/8 pneumatic working ports within an operating pressure range of -0.9 bar to 10 bar. Designed with a soft sealing principle, positive overlap, and an adjustable exhaust air function, it includes a mechanical spring reset method alongside detenting and non-detenting manual override options. It holds c UL us recognition and DNVGL-TAA000011J maritime classification, supporting mounting in any position with reversible flow direction. Submit the exact part number, quantity, and application requirements to receive a formal quotation.
View product details →
Festo
574461
Manifold rail VABM-L1-18S-G38-8
The Festo 574461 is an industrial component featuring a wrought aluminum alloy manifold rail with a width dimension of 19 mm, a product weight of 652 g, and support for a maximum of 16 valve positions. It operates within a pressure range of -0.09 MPa to 1 MPa (-0.9 bar to 10 bar) and includes pneumatic connections 1, 3, and 5 configured as G3/8 ports. Certified with the RCM compliance mark and c UL us recognition (OL), this RoHS-compliant part has a CRC rating of 2 for moderate corrosion stress, VDMA24364-B1/B2-L LABS conformity, ISO 14644-1 Class 5 cleanroom suitability, and suitability for the production of Li-ion batteries with reduced Cu/Zn/Ni values (F1a). Maximum tightening torques are specified at 1.5 Nm for DIN rail mounting, 1.18 Nm for valve mounting, and 3 Nm for wall mounting. Submit the exact part number, quantity, and application requirements for an RFQ.
View product details →
Festo
574102
Electric cylinder ESBF-BS-63-300-25P
The Festo 574102 is an electric cylinder with a ball screw based on the ISO 15552 norm, featuring a size 63 designation and a 300 mm working stroke. Driven by a servo motor with a maximum rotational speed of 3260 rpm, this component delivers a 25 mm/U spindle pitch, a 25 mm screw diameter, a maximum speed of 1.35 m/s, and a maximum acceleration of 25 m/s² with a repetition accuracy of ±0.01 mm and a reversing backlash of 40 µm. It includes an M16x1.5 external thread piston rod featuring a plain bearing-guide with a maximum angle of rotation of +/- 0.4 degrees, position sensing via proximity switch, and any mounting position. Submit the exact part number, quantity, and application requirements to receive a formal quotation.
View product details →SMC
EEX500-IB1-T8
SMC EEX500-IB1-T8 — Industrial Component
SMC part number EEX500-IB1-T8 is an industrial component manufactured by SMC. Please submit the exact part number, quantity, and application requirements to receive a quote for this item.
View product details →
Festo
575490
Air solenoid valve VUVS-L25-M32U-AD-G14-F8-1C1
The Festo part number 575490 is an electrical 3/2-way monostable open piston gate valve featuring a 26.5 mm valve size, a G1/4 pneumatic working port, and a normal nominal flow rate of 1000 l/min normalized to DIN 1343. Operating at 24V DC within a pressure range of 0.25 MPa to 1 MPa (2.5 bar to 10 bar), this piloted component utilizes internal pilot air supply, a soft sealing principle, a pneumatic spring reset method, and an adjustable exhaust air function with a nominal width of 6.3 mm. It includes both detenting and non-detenting manual override options, positive overlap lap, non-reversible flow direction, and any mounting position while achieving an IP65 degree of protection with a plug socket as per IEC 60529 and c UL us recognized (OL) certification. Submit the exact part number, quantity, and application requirements to request a quote for this industrial component.
View product details →
Festo
574460
Manifold rail VABM-L1-18S-G38-7
The Festo 574460 is an industrial component featuring a wrought aluminum alloy manifold rail with a width dimension of 19 mm, a product weight of 581 g, and a maximum of 16 valve positions. It supports an operating pressure range of -0.9 bar to 10 bar (-0.09 MPa to 1 MPa) and incorporates G3/8 pneumatic connections 1, 3, and 5. Certified with the RCM compliance mark and c UL us recognition (OL), this RoHS-compliant part meets ISO 14644-1 Class 5 cleanroom standards, VDMA24364-B1/B2-L LABS conformity, and CRC 2 moderate corrosion stress resistance while being suitable for Li-ion battery production with reduced Cu/Zn/Ni values (F1a). Submit the exact part number, quantity, and application requirements to request a quote.
View product details →
Festo
575602
Air solenoid valve VUVS-L30-M52-MD-G38-F8
This Festo 575602 industrial component is a 31 mm, 5/2-way monostable piston gate valve featuring electrical actuation and a piloted type of control with internal pilot air supply. It delivers a normal nominal flow rate of 2300 l/min through G3/8 pneumatic working ports, operating across a pressure range of 0.25 MPa to 1 MPa (2.5 bar to 10 bar) with an adjustable exhaust air function and a mechanical spring reset. The unit incorporates a soft sealing principle, a 9.4 mm nominal width, positive overlap lap, non-reversible flow direction, and supports any mounting position alongside detenting or non-detenting manual override. Certified by c UL us - recognized (OL) and holding maritime classification DNVGL-TAA000011J, please submit the exact part number, quantity, and application requirements to receive a formal quote.
View product details →
Festo
574101
Electric cylinder ESBF-BS-63-200-25P
The Festo 574101 is an electric cylinder with a ball screw based on the ISO 15552 norm, featuring a size 63 design with a 200 mm working stroke and a 25 mm screw diameter. This component incorporates a ball spindle type with a 25 mm/U pitch, an M16x1.5 external thread piston rod, a plain bearing-guide for torsion protection, and a 40 µm reversing backlash. Operating with any mounting position, it achieves a maximum speed of 1.35 m/s, a maximum rotational speed of 3260 rpm, a maximum acceleration of 25 m/s², and a repetition accuracy of ±0.01 mm alongside position sensing via a proximity switch and a servo motor type. Submit the exact part number, quantity, and application requirements to receive a formal quotation for this unit.
View product details →
Festo
575489
Air solenoid valve VUVS-L25-M32U-MZD-G14-F8
The Festo 575489 is an electrical 3/2-way monostable open industrial component featuring a piston gate valve structural design and a nominal width of 6.3 mm. Operating at a pressure range of -0.09 MPa to 1 MPa (-0.9 bar to 10 bar) with an external pilot air supply port, it delivers a normal nominal flow rate of 1000 l/min through G1/4 pneumatic working ports. This unit incorporates a mechanical spring reset method, soft sealing principle, adjustable exhaust air function, positive overlap lap, and both detenting and non-detenting manual override capabilities in any mounting position. It carries c UL us recognition and DNVGL-TAA000011J maritime classification certifications. Submit the exact part number, quantity, and application requirements for a formal quote.
View product details →
