Industrial sourcing catalog
Search by Manufacturer Part Number
Browse verified product records and request commercial availability, lead time and technical documentation.
Festo
7865
Reducing nipple D-1/8I-1/4A-NPT
The Festo reducing nipple D-1/8I-1/4A-NPT (Part Number: 7865) features VDMA24364-B1/B2-L LABS (PWIS) conformity and RoHS 6/6/26 material compliance according to the official Festo EN-US data sheet. Procure this specific industrial component for your installation by submitting the exact part number, required quantity, and application parameters for a formal quotation.
View product details →
Festo
6259
Elbow quick connector LCK-1/8-PK-4-KU
The Festo part number 6259 is an L-shaped industrial component featuring a 3.4 mm nominal width, an external thread G1/8 pneumatic connection 1, and a pneumatic connection 2 for 6 mm outside diameter tubing or 4 mm inside diameter barbed fittings with a POM union nut. It operates within a temperature range of -10 °C to 60 °C and an operating pressure of -0.095 MPa to 1 MPa using compressed air conforming to ISO 8573-1:2010 [7:-:-], with lubricated operation supported. This RoHS-compliant unit is constructed with a wrought aluminum alloy anodized hollow bolt and a POM swivel joint, offering moderate corrosion stress resistance (CRC 2) and any mounting position. Please submit the exact part number, quantity, and application requirements to receive a formal quotation.
View product details →
Festo
7862
PE converter PE-1/8-2N-SW
The Festo 7862 is a pneumatic-to-electric pressure transducer engineered to measure relative pressure within an operating range of 0 bar to 8 bar and a maximum overload pressure of 12 bar using compressed air according to ISO 8573-1:2010 [7:4:4] at temperatures between 0 °C and 60 °C. Conforming to EN 60947-5-1, this component features a contact-based changeover switch with a fixed hysteresis, a maximum switch-on point of 2 bar, a minimum switch-off point of 0.5 bar, and a maximum switching frequency of 1 Hz for AC and DC operating voltages from 12 V to 250 V with a minimum load current of 100 mA. It carries CE marking as per the EU low voltage directive and UKCA marking to UK instructions for electrical equipment, while allowing lubricated operation within a medium and ambient temperature range of 0 °C to 60 °C. Submit the exact part number, quantity, and application requirements for a formal quotation.
View product details →
Festo
8002281
Filter regulator LFR-1-D-MAXI-MPA
The Festo part number 8002281 is a Maxi-size D-series structural filter regulator with a pressure gauge, featuring a 40 µm filtration grade and a manual rotating condensate drain with an 80 cm³ max condensate volume inside a metal bowl guard. Operating within a 1 bar to 16 bar pressure range and a regulation range of 0.5 bar to 12 bar, this component supports a normal nominal flow rate of 10000 l/min for compressed air as per ISO 8573-1:2010 [-:9:-] or inert gases. The unit incorporates a rotary knob with detent for actuator locking, operates in a vertical ±5° mounting position, and is rated for moderate corrosion stress with CRC 2 and VDMA24364-B1/B2-L LABS conformity. Submit the exact part number, quantity, and application requirements to receive a formal quotation.
View product details →
Festo
8004663
Motor cable NEBM-M16G8-E-7.5-Q7-LE8
This Festo industrial component, part number 8004663, is built in accordance with the EN 61984 norm and features an 8-pin, 6-wire configuration on both ends. Electrical connection 1 utilizes a straight M16x0.75 round socket for the field device end, while electrical connection 2 provides an open-ended cable for the control side without a label holder. The part operates within a DC and AC voltage range of 0 V to 600 V, with a 0 V to 300 V limitation for a conductor cross-section of 0.25 mm², and delivers a current rating of 12 A at 40° C, which adjusts to 4 A for a 0.25 mm² conductor cross-section. Submit the exact part number, quantity, and application requirements for a quote.
View product details →
Festo
6258
Quick connector CK-1/4-PK-9-KU
This Festo industrial component, part number 6258, is a straight-design fitting featuring an external thread G1/4 on connection 1 and a barbed fitting for a 9 mm inside diameter with a nut on connection 2. Fabricated with a POM screwed plug and union nut utilizing a sealing edge, the unit accommodates any mounting position and operates within a pressure range of -0.095 MPa to 1 MPa for compressed air and up to 0.6 MPa for water at a maximum of 50 °C. The assembly supports lubricated operation across an ambient temperature range of -10 °C to 60 °C and requires a nominal tightening torque of 5.5 Nm with a ±20% tolerance. Submit the exact part number, quantity, and application requirements to receive a formal quotation for this 10-pack of RoHS-compliant components.
View product details →SMC
CKZT50-A045CS
SMC CKZT50-A045CS — Industrial Component
Source the SMC CKZT50-A045CS industrial component directly for your facility's assembly operations. This specific part is manufactured by SMC to meet precise operational parameters. Submit the exact part number, quantity, and application requirements for a quote.
View product details →
Festo
8002280
Filter regulator LFR-3/4-D-MAXI-MPA
The Festo 8002280 is a D-series Maxi structural filter regulator with an integrated pressure gauge, operating within an input pressure range of 1 bar to 16 bar and a regulation range of 0.5 bar to 12 bar. This unit delivers a normal nominal flow rate of 9700 l/min using compressed air meeting ISO 8573-1:2010 [-:9:-] or inert gases, featuring a 40 µm filtration grade, an 80 cm³ max condensate volume with a manual rotating drain, and a metal bowl guard. It is configured for a vertical ±5° mounting position, includes a rotary knob actuator lock with detent, and achieves an output air quality class of ISO 8573-1:2010 [7:8:4] while permitting oil lubrication operation. Submit the exact part number, quantity, and application requirements to request a quote for this component.
View product details →
Festo
8004662
Motor cable NEBM-M16G8-E-2.5-Q7-LE8
This Festo industrial component, part number 8004662, is manufactured based on norm EN 61984 and features a straight, round M16x0.75 socket connection with 8 pins and 6 occupied wires on the field device end, alongside an open-end cable connection with 8 pins and 6 occupied wires on the control side without a label holder. The unit operates within a DC and AC voltage range of 0 V to 600 V, which is limited to 0 V to 300 V for a conductor cross-section of 0.25 mm², and provides a current rating of 12 A at 40° C that drops to 4 A for a conductor cross-section of 0.25 mm². Submit the exact part number, quantity, and application requirements for a quote.
View product details →
Festo
6257
Quick connector CK-1/4-PK-6-KU
The Festo part number 6257 is a straight industrial component featuring a 5.3 mm nominal width, a G1/4 external thread for pneumatic connection 1, and an 8 mm outside diameter tubing connection or 6 mm inside diameter barbed fitting with a nut for pneumatic connection 2. Constructed with POM union nuts and screwed plugs utilizing a sealing edge design, this component operates across a pressure range of -0.95 bar to 10 bar for compressed air and up to 0.6 MPa for water at temperatures between -10 °C and 60 °C. It accommodates lubricated operation, conforms to VDMA24364-B1/B2-L LABS standards, and requires a nominal tightening torque of 5.5 Nm with a ±20% tolerance in a pack size of 10. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →
Festo
7849
Distributor block FR-4-1/4-C
The Festo part number 7849 is an industrial component featuring a die-cast aluminum housing with a nominal width of 11.5 mm and a product weight of 60 g. This unit includes one internal thread G1/4 supply line, three internal thread G1/4 outlets, and operates within an ambient temperature range of -10 °C to 80 °C. It supports compressed air operating media as per ISO 8573-1:2010 [7:-:-] from 0 bar to 16 bar across the entire temperature range, allows for optional oil lubrication, and maintains a corrosion resistance class of CRC 0. Submit the exact part number, quantity, and application requirements for a quote.
View product details →
Festo
8002279
Filter regulator LFR-1/4-D-MINI-MPA
The Festo 8002279 is a Series D mini filter regulator featuring an integrated pressure gauge, a 40 µm filtration grade, and a manual rotating condensate drain with a maximum condensate volume of 22 cm³. It operates within a pressure range of 1 bar to 16 bar, regulates pressure from 0.5 bar to 12 bar, and delivers a normal nominal flow rate of 1400 l/min using compressed air or inert gases. Built with a metal bowl guard and a rotary knob actuator lock with detent, the unit maintains a maximum pressure hysteresis of 0.2 bar and is rated for a vertical ±5° mounting position under moderate corrosion stress. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →SMC
CKZT50-A015CS
SMC CKZT50-A015CS — Industrial Component
The SMC CKZT50-A015CS is an industrial component manufactured by SMC. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →
Festo
6256
Quick connector CK-1/4-PK-4-KU
The Festo part number 6256 is a straight industrial component featuring a 3.4 mm nominal width, an external thread G1/4 pneumatic connection 1, and a pneumatic connection 2 for 6 mm outside diameter tubing or 4 mm inside diameter barbed fitting with a nut. Constructed with POM union nuts and screwed plugs utilizing a sealing edge, this RoHS-compliant part supports compressed air and liquid water operating media across a temperature range of -10 °C to 60 °C and an operating pressure from -0.095 MPa to 1 MPa. Supplied in a pack size of 10, it operates with a nominal tightening torque of 5.5 Nm within a ±20% tolerance and conforms to VDMA24364-B1/B2-L LABS conformity standards. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →
Festo
8004661
Motor cable NEBM-M16G8-E-7.5-Q9-LE8
The Festo 8004661 industrial component is built on the EN 61984 norm and features an 8-pin, 6-occupied pin straight M16x0.75 socket on the field device end with a cable designation without a label holder. On the control side, electrical connection 2 consists of an open-end cable with 8 pins and 6 occupied wires. This part operates across a DC and AC voltage range of 0 V to 600 V, rated for 0 to 300 V when utilizing a 0.5 mm² conductor cross-section. At a temperature of 40° C, the current rating reaches 16 A, dropping to 8 A for a conductor cross-section of 0.5 mm². Submit the exact part number, quantity, and application requirements to request a quote.
View product details →
Festo
7848
Round cylinder DGS-25- -PPV-A
The Festo part number 7848 is a double-acting industrial component featuring a 25 mm piston diameter and an adjustable stroke range of 10 to 500 mm with a single-ended piston rod. It operates on compressed air meeting ISO8573-1:2010 [7:4:4] standards at a working pressure between 1 and 12 bar, delivering a theoretical force of 295 N on the advance stroke and 247 N on the return stroke at 6 bar. Equipped with PPV pneumatic cushioning at both ends over a 16 mm cushioning length and provisions for proximity sensor position detection, it functions within an ambient temperature range of -20 to 80 °C via G1/8 pneumatic connections. Submit the exact part number, quantity, and application requirements to receive a quote.
View product details →
Danfoss Industrieautomatik
032U5709
Danfoss Industrieautomatik 032U5709 — Solenoid Valve
The Danfoss Industrieautomatik 032U5709 is a direct-acting NC solenoid valve featuring a brass housing, a G 1/4 port size, and a nominal size of 3.0 mm. It is equipped with EPDM seals and operates across a differential pressure range of 0 to 30 bar while accommodating media temperatures from -30 to 120 °C. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →
Festo
8002278
Filter regulator LFR-1/8-D-MINI-MPA
The Festo 8002278 is a mini D-series filter regulator featuring a structural design with an integrated pressure gauge, rotary knob with detent actuator lock, and a manual rotating condensate drain with a 22 cm³ max condensate volume inside a metal bowl guard. Operating within a 1 bar to 16 bar pressure range and a regulation range of 0.5 bar to 12 bar, this component achieves a normal nominal flow rate of 750 l/min while maintaining a 40 µm filtration grade for compressed air and inert gases. It operates in a vertical ±5° mounting position with moderate corrosion stress resistance and is compatible with oil lubrication. Submit the exact part number, quantity, and application requirements for an RFQ quote.
View product details →
Festo
6255
Quick connector CK-1/8-PK-6-KU
The Festo part number 6255 is a straight industrial component featuring a 4.4 mm nominal width, an external thread G1/8 pneumatic connection 1, and a pneumatic connection 2 for an 8 mm outside diameter tubing or a 6 mm inside diameter barbed fitting with a nut. Constructed with a POM union nut and screwed plug incorporating a sealing edge, this RoHS-compliant part supports compressed air and liquid water operating media across an operating pressure range of -0.95 bar to 10 bar. It operates within an ambient temperature range of -10 °C to 60 °C and has a nominal tightening torque of 3.25 Nm with a ±20% tolerance, packaged in a quantity of 10. Request a quote by submitting the exact part number, quantity, and application requirements.
View product details →
Festo
7843
Stem actuated micro valve S-3-PK-3-B
The Festo 7843 is a directly controlled 3/2-way closed monostable industrial component featuring a poppet valve structural design with a mechanical spring reset method. Built with a polymer and brass housing, this valve operates within a pressure range of -0.95 bar to 8 bar and achieves a normal nominal flow rate of 60 l/min through PK-3 pneumatic working ports. It incorporates a soft sealing principle, requires a 6 N actuating force, weighs 7 g, and supports any mounting position via through-holes. Submit the exact part number, quantity, and application requirements for a quote.
View product details →
