Industrial sourcing catalog
Search by Manufacturer Part Number
Browse verified product records and request commercial availability, lead time and technical documentation.

Festo
558215
Plastic tubing PLN-12X1,75-SI
The Festo 558215 is an industrial component featuring a 12 mm outside diameter, an 8.4 mm inside diameter, and a product weight by length of 0.054 kg/m in silver. Operating with compressed air as per ISO 8573-1:2010 [7:-:-] or liquid water, it supports a temperature-dependent operating pressure from -0.095 MPa to 1.4 MPa and an ambient temperature range of -30 °C to 80 °C. This TÜV-certified part (certificate B 013277 0527 00) accommodates a minimum bending radius of 23 mm alongside a flow-rate relevant bending radius of 65 mm for 12 mm plug connections. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →
Festo
558786
Push-in T-connector NPQM-T-Q4-E-P10
The Festo 558786 is a standard T-shaped industrial component featuring a nominal width of 3 mm and a push-pull structural design for 4 mm outside diameter pneumatic tubing connections. Constructed with a nickel-plated brass housing, an NBR tubing seal, and a silver releasing ring, this part operates within a pressure range of -0.95 bar to 16 bar and an ambient temperature range of -20 °C to 70 °C using compressed air per ISO 8573-1:2010 [7:-:-]. Each pack contains 10 units with a product weight of 12.5 g each, classified under corrosion resistance class 1 and adhering to RoHS and LABS conformity standards VDMA24364-B1/B2-L with lubricated operation enabled. Submit the exact part number, quantity, and application requirements for an RFQ quote.
View product details →
Festo
557395
Compact air cylinder ADN-5"- -
The Festo part number 557395 is a double-acting industrial component featuring a 5-inch piston diameter, an ISO 21287 norm design, and a stroke range from 0.039 in to 19.7 in utilizing elastic cushioning rings at both ends. Operating on compressed air per ISO 8573-1:2010 [7:4:4] within a 14.5 psi to 145 psi pressure range, this profile barrel actuator delivers a theoretical force of 1589 lbf retracting and up to 1655 lbf advancing at 6 bar. It incorporates a square piston rod for anti-twist protection, 1/4 NPT pneumatic connections, and position sensing capabilities for proximity sensors across any mounting position. Submit the exact part number, quantity, and application requirements to request a quote for this component.
View product details →
Festo
558214
Plastic tubing PLN-10X1,5-SI
This Festo industrial component, part number 558214, is a silver pneumatic tubing featuring a 10 mm outside diameter and a 7 mm inside diameter with a product weight of 0.0375 kg/m. It operates with compressed air as per ISO 8573-1:2010 [7:-:-] or liquid, ice-free water under a temperature-dependent operating pressure of -0.095 MPa to 1.4 MPa (-0.95 bar to 14 bar, or -13.775 psi to 203 psi), alongside a water maximum of 0.8 MPa at 0 to 50°C. The part maintains a minimum bending radius of 22 mm and a bending radius relevant for flow rate of 57 mm within an ambient temperature range of -30°C to 80°C. Submit the exact part number, quantity, and application requirements for a quote.
View product details →
Festo
559780
Proportional pressure regulator VPPM-6L-L-1-G18-0L10H-V1P
The Festo part number 559780 is a 3-way proportional-pressure regulator featuring a pilot-actuated diaphragm regulator design with soft sealing and electrical actuation via a mechanical spring reset. This component provides a pressure control range of 0.1 to 10 bar, an inlet pressure 1 of 0 to 11 bar, a nominal diameter of 6 mm for pressurization, and a nominal diameter of 4.5 mm for exhaust with a standard nominal flow rate of 1,400 l/min. Operating on a DC voltage range of 21.6 to 26.4 V with a 100% duty cycle and a maximum electrical power consumption of 7 W, it includes LED display, full short circuit and polarity protection, and a VPPM safety position maintaining unregulated output pressure if the power supply cable is interrupted. Submit the exact part number, quantity, and application requirements to receive a formal quotation.
View product details →SMC
AC20A-F02-A
SMC AC20A-F02-A — Industrial Component
The SMC part number AC20A-F02-A is an industrial component manufactured by SMC. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →
Festo
558784
Push-in L-connector NPQM-L-Q10-S10-P10
Festo part number 558784 is an L-shaped standard industrial component featuring a nominal width of 8 mm and a push-pull structural design with a pack size of 10. The unit operates within a pressure range of -0.095 MPa to 1.6 MPa (-0.95 bar to 16 bar / -13.775 psi to 232 psi) and an ambient temperature range of -20 °C to 70 °C utilizing compressed air as per ISO 8573-1:2010 [7:-:-] with lubricated operation possible. Constructed with a nickel-plated brass housing, NBR tubing seal, and a silver releasing ring, this 30 g component includes a 10 mm push-in sleeve for pneumatic connection 1 and accommodates 10 mm outside diameter pneumatic tubing for connection 2. Submit the exact part number, quantity, and application requirements for a quote.
View product details →
Festo
557390
Coupling EAMC-30-35-8-9
The Festo industrial component, part number 557390, features a size 30 designation with an 8 mm diameter for holder 1 and a 9 mm diameter for holder 2. This 45 g assembly operates with an omnidirectional mounting position at a maximum rotational speed of 8000 rpm, delivering a transferable torque of 8.2 Nm and a mass moment of inertia of 6.1 kgmm² over a 35 mm nominal length. Built with RoHS-compliant materials, the unit conforms to VDMA24364-B2-L LABS (PWIS) standards and functions within an ambient and storage temperature range of -25 °C to 60 °C alongside 0 to 95% relative air humidity. Submit the exact part number, quantity, and application requirements to receive a formal quotation.
View product details →
Festo
558213
Plastic tubing PLN-8X1,25-SI
The Festo part number 558213 is an industrial component featuring an 8 mm outside diameter, a 5.9 mm inside diameter, and a product weight of 0.0214 kg/m in silver. It operates with compressed air as per ISO 8573-1:2010 [7:-:-] or liquid, ice-free water, handling temperature-dependent operating pressures from -0.095 MPa to 1.4 MPa and ambient temperatures between -30 °C and 80 °C. Certified by TÜV under authority B 013277 0527 00, this RoHS-compliant component includes a 50 mm bending radius relevant for flow rate and a minimum bending radius of 23 mm. Submit the exact part number, quantity, and application requirements for a quote.
View product details →
Festo
558783
Push-in L-connector NPQM-L-Q8-S8-P10
The Festo part number 558783 is a standard, L-shaped industrial component featuring a 6 mm nominal width and a push-pull structural design packaged in a quantity of 10. Built with a nickel-plated brass housing, an NBR tubing seal, and a silver releasing ring, this RoHS-compliant part supports compressed air per ISO 8573-1:2010 [7:-:-] with lubricated operation possible across an operating pressure range of -0.095 MPa to 1.6 MPa and an ambient temperature range of -20 °C to 70 °C. It provides a push-in sleeve Ø 8 mm as pneumatic connection 1 and an 8 mm outside diameter pneumatic tubing accommodation for pneumatic connection 2, exhibiting a 20.5 g product weight and a CRC rating of 1. Submit the exact part number, quantity, and application requirements for a quote.
View product details →Filtration Group
77863814
Filtration Group 77863814 — Industrial Component
This Filtration Group industrial component, part number 77863814, is available for procurement directly from the manufacturer. Please submit the exact part number, quantity, and application requirements to request a formal quote.
View product details →
Festo
557377
Soft-start valve VABF-S6-1-P5A4-G12-4-1-P
The Festo 557377 is a piloted piston gate valve based on the ISO 5599-2 norm featuring electrical actuation, a soft sealing principle, and a mechanical spring reset method. It operates within a pressure range of 0.2 MPa to 1.2 MPa (2 bar to 12 bar) with a switchover pressure presetting of 0.4 MPa, utilizing internal pilot air supply and supporting a non-reversible flow direction with a pressurization valve function. This component incorporates both detenting and electrical self-resetting manual overrides, N.O. contact switching element function, and switching position sensing with a sensor, while withstanding severity level 2 vibration and shock resistance as per FN 942017-4, FN 942017-5, EN 60068-2-6, and EN 60068-2-27 standards. Submit the exact part number, quantity, and application requirements to request a quote for this item.
View product details →
Festo
558212
Plastic tubing PLN-6X1-SI
The Festo 558212 is a silver industrial component manufactured with protective grounding pneumatic tubing, featuring a 6 mm outside diameter and a 4 mm inside diameter. It operates within a temperature-dependent operating pressure range of -0.095 MPa to 1.4 MPa (-0.95 bar to 14 bar, -13.775 psi to 203 psi) for compressed air according to ISO 8573-1:2010 [7:-:-], and up to 0.8 MPa for water at 0 to 50°C, with an ambient temperature range of -30 °C to 80 °C and TÜV certification under authority B 013277 0527 00. This RoHS compliant part weighs 0.0147 kg/m, accommodates a minimum bending radius of 11 mm (with a 32 mm bending radius relevant for flow rate), adheres to VDMA24364-B2-L LABS conformity, and connects via plug connections for 6 mm outside diameters or barbed fittings for 4 mm inside diameters. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →SMC
AC20-F02E-B
SMC AC20-F02E-B — Industrial Component
The SMC AC20-F02E-B is an industrial component manufactured by SMC. Please submit the exact part number, quantity, and application requirements for a quote.
View product details →
Festo
558782
Push-in L-connector NPQM-L-Q6-S6-P10
The Festo 558782 is a standard L-shaped industrial component featuring a nominal width of 4 mm and a push-pull structural design with a silver releasing ring. Constructed with a nickel-plated brass housing, an NBR tubing seal, and a 17 g product weight, this part includes a 6 mm push-in sleeve as pneumatic connection 1 and accommodates 6 mm outside diameter pneumatic tubing at pneumatic connection 2. It operates across a pressure range of -0.095 MPa to 1.6 MPa (-0.95 bar to 16 bar, -13.775 psi to 232 psi) and an ambient temperature range of -20 °C to 70 °C using compressed air as per ISO 8573-1:2010 [7:-:-], with lubricated operation possible and a corrosion resistance class of 1. Supplied in a pack size of 10, the RoHS-compliant assembly conforms to VDMA24364-B1/B2-L LABS requirements. Submit the exact part number, quantity, and application requirements for a quote.
View product details →
Festo
559653
Air solenoid valve CPV14-M1H-2OLS-2GLS-K-1/8
The Festo 559653 is an electrical 14 mm piston gate valve featuring a 2x2/2, open/closed, monostable valve function with a normal nominal flow rate of 800 l/min and G1/8 pneumatic working ports. Operating at 24V DC across an operating pressure range of -0.9 bar to 10 bar (-0.09 MPa to 1 MPa), this piloted component incorporates a soft sealing principle, pneumatic spring reset method, and an IP65 degree of protection. Featuring internal or external pilot air supply ports with a pilot pressure of 0.3 MPa to 0.8 MPa, it also includes both detenting and non-detenting manual override options for any mounting position. Submit the exact part number, quantity, and application requirements for a quote.
View product details →
Festo
558211
Plastic tubing PLN-4X0,75-SI
The Festo part number 558211 is a silver industrial component featuring a 4 mm outside diameter, a 2.9 mm inside diameter, and a weight of 0.0056 kg/m. It operates with compressed air as per ISO 8573-1:2010 [7:-:-] and water at a temperature-dependent operating pressure ranging from -0.095 MPa to 1.4 MPa (-0.95 bar to 14 bar or -13.775 psi to 203 psi), maintaining a minimum bending radius of 12 mm and a 25 mm bending radius relevant for flow rate. Certified by TÜV under authority B 013277 0527 00, this RoHS compliant element functions in ambient temperatures from -30 °C to 80 °C with VDMA24364-B2-L LABS conformity and supports plug connections for 4 mm and 5/32" outside diameters as well as 3 mm inside diameter barbed fittings. Submit the exact part number, quantity, and application requirements for a quote.
View product details →
Festo
558781
Push-in L-connector NPQM-L-Q4-S4-P10
The Festo 558781 is a standard-sized, L-shaped industrial component featuring a 2.5 mm nominal width and a push-pull structural design packaged in a quantity of 10. Constructed with a nickel-plated brass housing, an NBR tubing seal, and a silver releasing ring, this RoHS-compliant part supports compressed air operation according to ISO 8573-1:2010 [7:-:-] across an operating pressure range of -0.95 bar to 16 bar and ambient temperatures from -20 °C to 70 °C. It accommodates a 4 mm push-in sleeve at pneumatic connection 1 and a 4 mm outside diameter pneumatic tubing at connection 2, providing a product weight of 14 g, CRC 1 low corrosion stress resistance, and VDMA24364-B1/B2-L LABS conformity with lubricated operation possible. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →
Festo
558210
Plastic tubing PLN-16X2-BL
The Festo 558210 is an industrial component featuring a 16 mm outside diameter, a 12 mm inside diameter, and a blue pneumatic tubing material of protective grounding with RoHS compliance. This part operates with compressed air as per ISO 8573-1:2010 [7:-:-] or liquid, ice-free water, handling temperature-dependent operating pressures from -0.095 MPa to 1.4 MPa (-0.95 bar to 14 bar / -13.775 psi to 203 psi) and water up to 0.8 MPa at 0 to 50 °C within an ambient temperature range of -30 °C to 80 °C. It carries TÜV certification under authority B 013277 0527 00, VDMA24364-B2-L LABS conformity, a weight of 0.082 kg/m, a minimum bending radius of 55 mm, and a bending radius relevant for flow rate of 95 mm for plug connections of 16 mm outside diameter. Submit the exact part number, quantity, and application requirements for a formal quotation.
View product details →
Festo
559652
Air solenoid valve CPV14-M1H-2X2-GLS-K-1/8
The Festo 559652 is a 14 mm electrical piston gate valve featuring a 2x2/2 closed, monostable configuration with a normal nominal flow rate of 800 l/min and G1/8 pneumatic working ports. This IP65-rated component operates at 24V DC across an operating pressure range of -0.09 MPa to 1 MPa (-0.9 bar to 10 bar) and utilizes piloted control with internal or external pilot air supply options, a soft sealing principle, and both detenting and non-detenting manual override capabilities. Featuring a pneumatic spring reset method, positive overlap lap, and a nominal width of 6 mm, it accommodates a pilot pressure of 0.3 MPa to 0.8 MPa in any mounting position with a non-reversible flow direction and non-throttleable exhaust air function. Submit the exact part number, quantity, and application requirements to request a quote for this industrial component.
View product details →
